In many projects, actuator selection starts with a simple assumption:
“As long as the force is sufficient, the system will work.”
That assumption often holds true — until the window becomes larger, heavier, or driven by more than one actuator.
Once multiple actuators are involved, the problem is no longer about force alone.
It becomes a question of movement coordination.
And when that coordination fails, the consequences are rarely minor.
Why Synchronization Matters in Multi-Actuator Window Systems
In single-actuator applications, the system behavior is predictable.
The actuator extends, the window opens, and the load path is relatively simple.
But in multi-actuator systems — especially in:
- Large façade windows
- Top-hung or bottom-hung ventilation windows
- Smoke ventilation systems
- Skylights or long-span glass panels
— the situation changes completely.
Now, instead of one driving point, you have two or more actuators trying to move the same structure at the same time.
If they move perfectly together, the system behaves as intended.
If they don’t, the system starts to fight itself.
What Happens When Actuators Are Not Synchronized?
In real-world projects, lack of synchronization typically leads to:
- Window twisting or frame deformation
One side opens faster, forcing the structure into stress. - Increased mechanical resistance
The slower actuator is effectively “dragging” against the faster one. - Actuator overload and premature failure
Motors draw higher current trying to compensate for uneven load. - Seal failure and long-term air/water leakage issues
Misalignment affects how the window closes over time. - Complete system jamming (in severe cases)
Especially common in large or rigid window structures.
This is why in any serious window automation system engineering considerations, synchronization is not an optional feature — it is a core design requirement.
Why “Equal Specifications” Do Not Guarantee Synchronization
A common misconception is:
“If I use two identical actuators, they will naturally move at the same speed.”
In practice, this is rarely true.
Even actuators with identical specifications will behave differently once installed.
Because synchronization is influenced by system-level variables, not just product specs.
What Causes Window Actuators to Go Out of Sync
Let’s break this down from an engineering perspective.
Load Imbalance Across the Window
Even in a perfectly manufactured window, the load is rarely distributed evenly.
Factors include:
- Glass weight distribution
- Frame stiffness variations
- Wind pressure differences
- Friction at hinges or seals
As a result:
- One actuator may carry more load than the other
- Higher load → lower speed
- Lower load → higher speed
Over time, this creates position drift between actuators
Installation Misalignment
Installation is one of the most underestimated causes of synchronization issues.
Typical problems include:
- Slight differences in mounting position
- Unequal stroke alignment
- Non-parallel actuator installation
- Frame tolerances in construction
Even a few millimeters of deviation can lead to:
- Different effective stroke lengths
- Uneven force distribution
- Progressive desynchronization during operation
This is why synchronization problems often do not appear immediately, but after repeated cycles.
Motor Performance Variations
No two motors are perfectly identical.
Even within the same production batch:
- Speed tolerance exists (e.g., ±5–10%)
- Internal friction varies
- Gear efficiency differs slightly
Under load, these small differences become amplified.
For example:
- Actuator A: slightly faster, slightly lower load
- Actuator B: slightly slower, slightly higher load
After multiple cycles, the difference becomes visible — and eventually problematic.
Power Supply and Control Differences
In many basic installations, actuators are simply wired in parallel.
This introduces additional variables:
- Voltage drop across wiring
- Unequal cable lengths
- Different contact resistances
- Control signal timing differences
These factors lead to:
- Slight differences in motor speed
- Delayed start/stop behavior
- Inconsistent response under load
In small windows, this may be negligible.
In large systems, it becomes a primary cause of synchronization failure.
The Core Insight: Synchronization Is a System Problem
At this point, one conclusion should be clear:
Synchronization is not something you “get” by choosing the right actuator.
It is something you design into the system.
This is where many projects go wrong.
They focus on:
- Force
- Stroke
- Speed
But overlook:
- Load distribution
- Installation tolerance
- Control strategy
And without addressing those, even the best actuators cannot prevent desynchronization.
If you’re working on large or multi-point window systems, this is exactly why a structured approach to electric window actuator system design becomes critical — not just for performance, but for long-term reliability.
Synchronization Methods: How It’s Actually Achieved in Practice
Once you understand that synchronization is a system-level issue, the next question becomes straightforward:
How do you actually keep multiple window actuators moving together?
In real projects, there are three main approaches — each with very different levels of complexity, cost, and reliability.
Mechanical Synchronization (Linkage-Based Systems)
The most traditional way to ensure synchronization is not through electronics, but through mechanical linkage.
Instead of relying on two actuators to “behave the same,” this method physically forces them to move together.
How It Works
- Two actuators are connected through:
- Rigid rods
- Drive shafts
- Gear linkage systems
- Movement from one side is directly transferred to the other
- The entire system behaves as a single mechanical unit
Why It Works
Because synchronization is no longer “controlled” — it is structurally enforced.
Even if:
- One actuator produces slightly more force
- Or one side encounters higher resistance
The linkage ensures that both sides move together.
Limitations
However, mechanical synchronization comes with clear constraints:
- Installation complexity increases significantly
- Requires precise alignment and rigid structural support
- Difficult to implement in long-span or irregular window designs
- Limited flexibility for architectural customization
In modern façade systems, purely mechanical synchronization is less common, but still used in certain heavy-duty or industrial applications.
Electrical Synchronization (Parallel Control / Sync Controllers)
This is the most commonly used approach in practical window automation systems.
Instead of linking actuators mechanically, the system attempts to drive them in parallel using electrical control.
Basic Parallel Control (Open-Loop)
In its simplest form:
- Multiple actuators are connected to the same power supply
- They receive the same voltage and control signal
This is often seen in cost-sensitive projects.
The Problem with Open-Loop Systems
Open-loop systems assume:
“If the input is the same, the output will be the same.”
As we discussed earlier, this assumption breaks down due to:
- Load differences
- Motor variation
- installation tolerance
Which leads to:
- Gradual drift
- Uneven movement
- Long-term synchronization failure
Controller-Based Synchronization
To improve reliability, many systems introduce a dedicated synchronization controller.
These controllers:
- Distribute power more evenly
- Regulate start/stop timing
- In some cases, limit current per actuator
This reduces — but does not eliminate — synchronization errors.
Where Electrical Synchronization Works Best
- Medium-size windows
- Dual actuator systems
- Projects where small deviation is acceptable
It offers a good balance between:
- Cost
- Complexity
- Performance
This is why it is widely used in many automatic window actuator solutions today.
Smart Synchronization (Closed-Loop / Feedback Control)
For high-performance systems, synchronization is no longer based on assumptions — it is based on real-time feedback.
How It Works
Each actuator is equipped with:
- Position sensors (e.g., encoders or Hall sensors)
- Feedback signals sent to a controller
The control system continuously:
- Monitors actuator positions
- Compares differences
- Adjusts speed or power output dynamically
What This Solves
Closed-loop systems directly address the root causes of desynchronization:
- Load imbalance → compensated in real time
- Motor variation → corrected continuously
- Drift over time → automatically adjusted
Instead of preventing differences, the system actively corrects them.
Trade-Offs
This level of control comes with higher requirements:
- More complex wiring and system integration
- Higher cost (hardware + control system)
- Need for proper configuration and commissioning
But in return, you get:
- High precision synchronization
- Long-term stability
- Better system reliability in demanding environments
Typical Applications
Closed-loop synchronization is typically used in:
- Large façade systems
- Smoke ventilation systems
- High-end architectural projects
- Critical safety-related installations
In these scenarios, synchronization is not optional — it is part of the system safety strategy.
Comparison of Synchronization Methods
To make the differences clearer, here is a practical comparison:
| Method | Principle | Advantages | Limitations | Suitable Scenarios |
|---|---|---|---|---|
Mechanical Synchronization |
Physical linkage enforces equal movement |
Highly reliable, no drift, independent of electrical variation |
Complex installation, low flexibility, difficult for large spans |
Industrial systems, rigid structures |
Electrical (Open-Loop) |
Same power and signal to all actuators |
Low cost, simple wiring |
Prone to drift, no correction mechanism |
Small windows, low-risk applications |
Electrical (Controller-Based) |
Central controller manages power and timing |
Improved consistency, moderate cost |
Still limited without feedback |
Medium-sized systems, dual actuators |
Smart (Closed-Loop) |
Real-time feedback adjusts actuator behavior |
High precision, adaptive, reliable long-term |
Higher cost, more complex setup |
Large windows, critical systems |
Choosing the Right Method Is a System-Level Decision
There is no “best” synchronization method in isolation.
The right choice depends on:
- Window size and structural rigidity
- Number of actuators
- Acceptable synchronization tolerance
- Budget and system complexity
- Safety requirements
In other words:
Synchronization strategy is not a product feature — it is part of the overall window automation system engineering considerations.
And this is exactly where many projects underestimate the problem — they choose actuators first, and only think about synchronization after issues appear on-site.
Engineering Challenges in Multi-Actuator Synchronization
Even with the right synchronization method selected, real-world projects still face challenges that are often underestimated during design.
Tolerance Accumulation
In theory, small deviations don’t matter.
In practice, they accumulate.
- Installation tolerance
- Structural deformation
- Manufacturing variation
Each factor may only introduce a small error.
But when combined, they can lead to:
- Noticeable actuator position drift
- Increased mechanical stress
- Reduced system lifespan
This is why synchronization problems often appear after months of operation, not during initial testing.
Dynamic Load Changes
Window systems are not static.
Load conditions change continuously due to:
- Wind pressure (especially in high-rise buildings)
- Temperature-induced expansion or contraction
- Aging of seals and hinges
As load distribution shifts:
- One actuator may suddenly carry more force
- Speed differences become more pronounced
- Previously stable systems start drifting
This is particularly critical in large façade applications.
Speed Drift Over Time
Even if actuators start perfectly synchronized, they rarely stay that way.
Reasons include:
- Gear wear
- Lubrication changes
- Motor aging
- Internal friction increase
Over time:
- Faster actuators become slightly slower
- Slower ones may degrade further under load
Without correction mechanisms, this leads to progressive desynchronization.
Environmental Factors
Environmental conditions play a bigger role than many expect:
- Low temperatures → increased viscosity → slower movement
- High temperatures → reduced motor efficiency
- Humidity → increased friction or corrosion
- Dust → mechanical resistance
These factors do not affect all actuators equally, which further contributes to synchronization issues.
When Do You Really Need Synchronization? (And When You Don’t)
Not every system requires strict synchronization.
Understanding this distinction is critical for both cost control and system design efficiency.
Synchronization Is Critical When:
- The window is large or structurally rigid
- Multiple actuators are mounted on the same moving frame
- The system requires tight sealing performance
- The application involves safety functions (e.g., smoke ventilation)
- Visible misalignment is unacceptable (architectural projects)
In these cases:
Even small differences in actuator movement can cause serious issues.
Synchronization May Be Optional When:
- The window is small or flexible
- Actuators are not mechanically coupled through a rigid structure
- Minor positional differences do not affect performance
- The system operates under low load conditions
In such scenarios:
- Simple electrical control may be sufficient
- Over-engineering synchronization can unnecessarily increase cost
A Practical Rule of Thumb
If the window structure cannot absorb movement differences,
you must enforce synchronization.
If the structure can tolerate slight deviation,
you may allow limited drift.
Best Practices for Designing Synchronized Window Actuator Systems
From an engineering standpoint, synchronization should be addressed early in the design phase, not after installation problems occur.
Start with Load and Structure Analysis
Before selecting actuators:
- Evaluate window size, weight, and stiffness
- Identify potential load imbalance
- Determine number and placement of actuators
Synchronization requirements should be defined at this stage — not later.
Minimize Installation Variability
Many synchronization issues originate from installation, not hardware.
Best practices:
- Ensure symmetrical mounting positions
- Maintain consistent actuator angles
- Control installation tolerances as much as possible
Even a well-designed system can fail if installation quality is poor.
Avoid Over-Reliance on Open-Loop Control
Parallel wiring may seem sufficient during testing, but:
- It does not compensate for real-world variations
- It cannot correct drift over time
For anything beyond simple applications, consider:
- Controller-based systems
- Or feedback-enabled solutions
Match Actuator Performance Carefully
Even within the same model:
- Verify speed consistency
- Avoid mixing batches or specifications
- Consider pre-matching actuators in critical projects
This reduces initial deviation before synchronization strategies take effect.
Design with Safety Margin
Do not design synchronization at the limit.
Allow margin for:
- Load variation
- Environmental changes
- Long-term wear
This is a key part of robust electric window opener selection guide practices — not just for force, but for system reliability.
Plan for Maintenance and Adjustment
Synchronization is not a “set once and forget forever” feature.
Systems should allow:
- Inspection access
- Adjustment capability
- Troubleshooting procedures
Especially in large-scale projects, this significantly reduces lifecycle cost.
Conclusion: Synchronization Is a Design Strategy, Not a Feature
It’s easy to think of synchronization as a technical add-on — something handled by controllers or electronics.
But in reality:
Synchronization reflects how well the entire system has been designed.
From:
- Load distribution
- Mechanical alignment
- Control strategy
To:
- Installation quality
- Long-term operating conditions
Everything contributes to whether actuators move together — or against each other.
This is why experienced integrators treat synchronization as a core part of system engineering, not just a product specification.
If you’re working on complex or large-scale projects, taking a structured approach to electric window actuator system design is not just beneficial — it’s essential for avoiding costly failures later.
FAQ — Practical Questions About Actuator Synchronization
Do all multi-actuator window systems require synchronization?
No, not all systems require strict synchronization.
If the window is small, lightweight, or structurally flexible, minor differences in actuator movement may not significantly affect performance.
However, in larger or rigid systems, especially where multiple actuators drive the same frame, synchronization becomes essential. Without it, even small deviations can lead to structural stress, misalignment, or long-term damage.
The key is to evaluate whether the structure can tolerate movement differences.
What happens if window actuators are not synchronized?
When actuators are not synchronized, the system experiences uneven movement.
Typical consequences include:
- Twisting or deformation of the window frame
- Increased resistance and motor load
- Premature wear of mechanical components
- Potential system jamming in severe cases
Over time, this can lead to both performance degradation and increased maintenance costs.
Can two actuators be connected directly without a controller?
Yes, but only in simple applications.
Direct parallel connection is common in cost-sensitive systems. However, it relies on the assumption that both actuators behave identically — which is rarely true in practice.
Without a controller or feedback mechanism, the system cannot compensate for:
- Load differences
- Motor variation
- Installation errors
This makes it unsuitable for large or critical applications.
What is the difference between open-loop and closed-loop synchronization?
Open-loop systems operate without feedback.
They assume that equal input results in equal output.
Closed-loop systems, on the other hand:
- Monitor actuator position in real time
- Compare differences between actuators
- Adjust movement dynamically
This allows closed-loop systems to actively correct synchronization errors, making them significantly more reliable in demanding environments.
How much synchronization error is acceptable in real projects?
There is no universal standard.
Acceptable error depends on:
- Window size
- Structural rigidity
- Application requirements
In small systems, a few millimeters of difference may be acceptable.
In large façade or smoke ventilation systems, even small deviations can be problematic.
Engineers typically define tolerance based on how much deformation the structure can safely absorb.
Why do actuators drift over time even if initially synchronized?
Drift occurs due to gradual changes in system behavior.
Common causes include:
- Mechanical wear
- Changes in friction
- Motor aging
- Environmental influences
Even if actuators start synchronized, these factors introduce small differences that accumulate over repeated cycles.
Without correction mechanisms, drift is almost inevitable.
Is mechanical synchronization more reliable than electronic methods?
Mechanical synchronization can be very reliable because it physically enforces equal movement.
However, it lacks flexibility and is more difficult to install.
Electronic and feedback-based systems offer greater adaptability and are better suited for modern architectural applications.
The choice depends on project requirements rather than reliability alone.
How to troubleshoot synchronization issues in installed systems?
Troubleshooting typically involves:
- Checking installation alignment
- Verifying load distribution across the window
- Measuring actuator speed differences
- Inspecting wiring and voltage consistency
- Evaluating control system behavior
In many cases, synchronization issues are caused by a combination of factors rather than a single fault.
A systematic approach is essential to identify the root cause.
If you’re designing or sourcing solutions for multi-actuator window systems, synchronization should be evaluated early — not after installation issues appear.
Explore our full range of automatic window actuator solutions, or contact our team for support on large or complex window automation projects.
smoke extraction. Full OEM/ODM technical support.
